Rolls RD320 (Occasion)

The RD320 is a mono digital delay processor. Specifically designed for delay speaker / stacks.
The unit has two modes (adjustable with a jumper, behind the protection plate);

Mode 1: delay range 5 - 320 millisecondsMode
2: delay range 40 - 1280 microsecondsThe

delay time, in,- and output level is easily adjustable behind the protection plate. Very reliable, solid unit.

Is new in the box, so in new condition!

FEATURES:
- Two delay increment modes - 5 to 320 ms, or 40 to 1280 ms-
Input and Output level controls, delay setting switches and mode switch-
All located behind handy security cover-
Five-segment LED input level meter-
Screw terminal input and output connectionsSPECIFICATIONS

:
- Frequency Response: 20Hz - 17kHz +/-3dB-
Input Impedance: 10kW balanced-
Output Impedance: 100W balanced-
Max Input: +21 dBV-
Max Output: +21 dBV-
Long Delay Range: 5 - 320 milliseconds (can be modified for 1280 ms)
- Long Delay Resolution: 5 milliseconds-
Short Delay Range: 40 ms - 2.56 ms-
Short Delay Resolution: 20 ms-
THD: .09%-
Connectors: Screw Terminals-
Size: 1.75" x 6" x 19" (44mm x 152mm x 483mm)

More Information

Brand	Rolls
Article number	45008
