The Opsix FM synthesizer, Korg's fresh and expansive reinvention of classic digital synthesis, delivers great versatility and full-spectrum, high-definition sound in an easy-to-use synth. From bells and chimes to crisp leads and woolly bass lines, the Opsix can handle it all thanks to a unique "altered" FM synthesis approach. By bypassing the often frustrating drawbacks of complex traditional 6-operator FM (Frequency Modulation) sound generation in favor of a much more musical and direct approach, the Opsix houses a stunning amount of power packed into a neat, 37-key chassis with accessible hands-on controls that give you the real-time sound-shaping you'd previously expect to find on an analog synth. At the heart of this synth's comprehensive voice is the Operator Mixer, a series of six backlit knobs and faders connected to various parameters for tonal tweaking at your discretion. Turn it on, and you're immediately presented with hundreds of presets that provide a solid foundation from which to explore.
Like having six synths at the ready
Read more
Korg's modern approach to FM
When the first digital synthesizers hit the market in the early 1980s, many keyboardists found them frustratingly complicated to use, despite their obvious potential. With the Opsix, Korg took a fresh, modern approach to FM. Their "modified" 6-operator FM synthesis makes the hugely capable FM sound generation method accessible to any musician who has ever played a classic analog synth. Equipped with a user-friendly 6-fader operator level mixer, 6-button ratio mixer, six data entry rotary encoders, and a flexible sound engine that takes you well beyond basic FM, the Opsix broadens the possibilities of digital synthesis. Whether you're an '80s FM purist or completely new to digital synthesis, the Korg Opsix is a must-have addition to your synth arsenal.Stunning power under the hood
The Korg Opsix may be small, but it has amazing sonic power. With 250 expertly curated factory presets (and 250 user slots), you can get started right away. From there, shaping your sound with the Opsix is almost as intuitive as any analog synth you've ever held in your hands. Analog experts will feel right at home with the Opsix's 21 oscillator waveforms, three envelopes, three LFOs and 11 powerful filters, while Korg's versatile V.Patch virtual patch system keeps routing simple. Use the Opsix's 16-step polyphonic sequencer. Load notes into the 7-pattern arpeggiator. Or use the Randomize function for some delightful unpredictability. FM synthesis has never been so accessible - and fun!Specifications:
- FM synthesizer
- altered
- polyphony: max 32 stereo
- sound source: FM
- structure: 6 operators, 1 filter, 3 EGs, 3 LFOs, 3
- effects, step sequencer, arpeggiator
- algorithm: 40 presets + user algorithm (unique for each program)
- operator: 5 modes (FM, Ring Mod, Filter, Filter FM, Wave Folder)
- oscillator: 21 waveforms (Sine, Sine 12bit, Sine 8bit, Triangle, Saw, Saw HD, Square, Square HD, Additive Saw3, Additive Sqr3, Additive Tri3, Additive 12345, Additive 1 + 2, Additive 1 + 3, Additive 1 + 4, Additive 1 +5, Additive 1 + 6, Additive 1 + 7, Additive 1 + 8, Noise S / H, Noise White)
- filter: 11 types (LPF 12, LPF 24, LPF MS-20, LPF POLY6, HPF 12, HPF 24, HPF MS-20, BPF 6, BPF 12, BRF 6, BRF 12)
- EG: ADSR
- LFO: 23 waveforms (Triangle, Saw Down, Saw Up, Square, Sine, Sample & Hold, Guitar, Exp. Triangle, Exp. Saw Down, Exp. Saw Up, Step4 Triangle, Step6 Triangle, Step4 Saw Down, Step6 Saw Down, StepRnd: Time, StepRnd: Lvl & Time, StepRnd: Level, Random: Time, Random: Lvl & Time, Triangle +, Saw Down +, Saw Up +, Square +)
- v.patch: 12 routing options
- effects: 30 types (Chorus, Unison Ensemble, Phaser, Phaser (BPM ), Auto Pan, Auto Pan (BPM), Flanger, Flanger (BPM), Rotary Speaker, Auto Wah, Exciter, Enhancer, LFO filter, 3-band EQ, Distortion, Guitar Amplifier, Decimator, Grain Shifter, Master Limiter, Compressor , Delay, Delay (BPM), Autopan Dly, Autopan Dly (BPM), Tape Echo, Tape Echo (BPM), Early Reflection, Reverb, Shimmer Reverb, Spring Reverb)
- sequencer:
step sequencer (up to 16 steps, up to 6 notes per step)
motion sequencer (up to 6 lanes) - arpeggiator: 7 patterns (MANUAL, UP, DOWN, ALT1, ALT2, RANDOM, TRIGGER)
- number of programs: 500 (250 preset programs and 250 user programs as factory settings)
- favorites: 64 (16 slots × 4 banks)
- controls:
MODULATION wheel
PITCH wheel
RATIO ON 1-6 buttons
LEVEL ON 1-6 sliders
DATA ENTRY A-F buttons - inputs and outputs:
headphones (6.3 mm stereo phone jack)
OUTPUT L / MONO and R (impedance-balanced 6.3 mm TRS phone jacks )
DAMPER (6.3 mm phone jack, half-damper not supported)
MIDI IN and OUT connectors
USB B port
power supply: AC adapter (DC12V) - power consumption: 5 W
- dimensions: 565 × 338 × 90 mm
- weight 2.9 kg
- included: AC adapter
- optional (sold separately): DS-1H pedal, PS-1 pedal, PS-3 pedal
Included is the AC adapter.
