The Cordial CSE 10 NN 7 is a network data cable with etherCON connectors. Length of the cable is 10 meters. The Hirose RJ-45 connectors are carried in a protective Neutrik metal housing NE8MX-B-1 (etherCON). The CSE NN 7 is particularly suitable for the transmission of very high data rates (CAT 7). The cable is equipped with transparent shrink sleeves for easy labeling.
The cable is solidly constructed and suitable for live-sound 'on the road' applications. The cable is somewhat stiff due to the PUR material of the jacket.
- Cordial type network cable: CCAT 7
- length: 10 meter
- professional look because of the black cable and black connectors
- S/FTP shielding
- conductor area: 0,14 mm²
- AWG 26
- conductor composition: 7 x 0.16 mm
- material: bare copper
- conductor resistance 145 Ohm/km
- capacitance: 45 nF/km
- diameter 6,3 mm
- weight 33 gr. / mtr.
- insulation of conductors: foam PE
- Cordial order no.: 11144
