The Cordial CIM 3 MV is a short cable for connecting audio equipment or microphone. The cable is equipped with two 3-pin XLR connectors. Length 300cm.
Quality
The cable is based on the Cordial Essentials Cable bulk cable and offers a conductor area of 0.22mm² (AWG 24) and spiral shielding of the copper wires. The composition of the conductors (28 x 0.10 mm) makes it very flexible and easy to coil. The CIM FM microphone cable features REAN SILVER® by NEUTRIK XLR® connectors in discreet black.Specifications:
- length: 3 mtr.
- XLR male- TRS jack- diameter cable: 5.9 mm
- AWG (American Wire Gauge**): AWG 24
- Resistance (Conductor resistance): 80 Ohm/km
- Capacitance (Capacity cond.): 80 pF/m
**AWG means American Wire Gauge and is an American standard that specifies the cross-sectional area of a round wire by a numerical code. It is important to remember that the size of the wire is measured without insulation. The higher the number, the smaller the diameter and the thinner the wire. Thicker wire carries more current by creating less electrical resistance over a given length. Thicker wire is therefore better for longer distances.**TRS jack means Tip Ring Sleeve jack. Also sometimes (incorrectly) called stereo jack. TRS is a balanced jack.
This is Cordial
"The name CORDIAL stands for first-class quality and high reliability from entry level to pro level."This credo has been maintained since the founding of the company CORDIAL and has remained the guiding principle for product development and quality management.
CORDIAL was founded in the early 1990s as a division of the company Hermann Adam in Dachau near Munich. Since 1995 it has been an independent company supplying bulk and turnkey cables to musicians and pro audio customers.
Cordial has a very wide range of products - from instrument, microphone and speaker cables to multi-core systems and adapters to DMX, MIDI and digital audio cables. Their products are innovative and not only follow the latest trends, but often set them.
That is why CORDIAL is among the one of the most important manufacturers when it comes to cables. With a clear conscience, the company can be called a trendsetter in the field of audio and video signals.
CORDIAL expanded abroad early on; today the company has production facilities at its headquarters in Germany, Europe and China, ensuring a reliable and stable supply chain. CORDIAL products are sold and appreciated worldwide for their excellent quality and durability.
